Field Description
• Any (default value): The route is valid for all port numbers.
• Single: Enables the entry of a port number.
• Range: Enables the entry of a range of port numbers.
• Private: Entry of privileged port numbers: 0 ... 1023.
• Server: Entry of server port numbers: 5000 ... 32767.
• Clients 1: Entry of client port numbers: 1024 ... 4999.
• Clients 2: Entry of client port numbers: 32768 ... 65535.
• Not privileged: Entry of unprivileged port numbers: 1024
... 65535.
Enter the appropriate values for the individual port or start port
of a range in Port and, for a range, the end port in to Port.
DSCP / TOS Value Select the Type of Service (TOS).
Possible values:
• Ignore (default value): The type of service is ignored.
• DSCP: Relates to a Differentiated Services Code Point to RFC
3260.
• TOS Binary Value: The TOS value is specified in binary
format, e.g. 00111111.
• TOS Decimal Value: The TOS value is specified in decimal
format, e.g. 63.
Enter the relevant value for DSCP, TOS Binary Value and
TOS Decimal Value.
Mode Select when the interface defined in Route Parameters -> In-
terface is to be used.
Possible values:
• Dialup and wait (default value): The route can be used if
the interface is "up". If the interface is "dormant", then dial and
wait until the interface is "up".
• Authoritative : The route can always be used.
• Dialup and continue: The route can be used if the inter-
face is "up". If the interface is "dormant", then select and use
the alternative route (rerouting) until the interface is "up".
Funkwerk Enterprise Communications GmbH
12 Routing
bintec W1002/W1002n/W2002/WIx040/WIx065 181
