Fig. 87: Routing ->RIP->RIP Filter->New
The Routing->RIP->RIP Filter->New menu consists of the following fields:
Fields in the RIP Filter Basic Parameters menu
Field Description
Interface Select the interface to which the rule to be configured applies.
IP Address/Netmask Enter the IP address and netmask to which the rule is to be ap-
plied. This address can be in the LAN or WAN.
The rules for incoming and outgoing RIP packets (import or ex-
port) for the same IP address must be separately configured.
You can enter individual host addresses or network addresses.
Direction Select whether the filter applies to the export or import of routes.
Possible values:
• Import (default value)
• Export
Metric Offset on Inter-
face up
Select the value to be added to the route metric if the status of
the interface is "up". During export, the value is added to the ex-
ported metric if the interface status is "up".
Possible values are -16 to 16.
12 Routing Funkwerk Enterprise Communications GmbH
194 bintec W1002/W1002n/W2002/WIx040/WIx065
