Field Description
Robustness Select the multiplier for controlling the timer values. A higher
value can e.g. compensate for packet loss in a network suscept-
ible to loss. If the value is too high, however, the time between
logging off and stopping of the data traffic can be increased
(leave latency).
Possible values are 2 to 8.
The default value is 2.
Response interval (last
member)
Define the time after a query for which the router waits for an
answer.
If you shorten the interval, it will be more quickly detected that
the last member has left a group so that no more packets for
this group should be forwarded to this interface.
Possible values are 0 to 255.
The default value is 1.
Maximum number of IG-
MP status messages
Limit the number of reports/queries per second for the selected
interface.
Mode Specify whether the interface defined here only works in host
mode or in both host mode and routing mode.
Possible values:
• Host and Routing (default value): The interface is oper-
ated in routing mode and in host mode.
• Host only: The interface is only operated in host mode.
IGMP Proxy
IGMP Proxy enables you to simulate several locally connected interfaces as a subnet to an
adjacent router. Queries coming in to the IGMP Proxy interface are forwarded to the local
subnets. Local reports are forwarded on the IPGM Proxy interface.
Funkwerk Enterprise Communications GmbH
12 Routing
bintec W1002/W1002n/W2002/WIx040/WIx065 205
