Funkwerk W1002 User Manual

this, enable the Show administrative access rules option.
15.1.1.1 New
Choose the New button to set up new parameters.
Fig. 117: Firewall->Policies->Filter Rules->New
The Firewall->Policies->Filter Rules->New menu consists of the following fields:
Fields in the Policies Basic Parameters menu
Field Description
Source Select one of the preconfigured aliases for the source of the
packet.
The list includes all WAN-/LAN interfaces, interface groups (see
Firewall -> Interfaces -> Groups), addresses (see Firewall ->
Addresses -> Address List) and address groups (see Firewall
-> Addresses -> Groups) for selection.
The value Any means that neither the source interface nor the
source address is checked.
Destination Select one of the preconfigured aliases for the destination of the
packet.
The list includes all WAN-/LAN interfaces, interface groups (see
Firewall -> Interfaces -> Groups), addresses (see Firewall ->
Addresses -> Address List) and address groups (see Firewall
-> Addresses -> Groups) for selection.
15 Firewall Funkwerk Enterprise Communications GmbH
278 bintec W1002/W1002n/W2002/WIx040/WIx065
