Field Description
Possible values:
• Automatic (default value): The IP address is determined
automatically.
• Specific: Enter the IP address in the adjacent input field.
Interval Enter the time interval (in seconds) to be used for checking the
availability of hosts.
Possible values are 1 to 65536.
The default value is 10.
The smallest Interval of the group members is used within a
group.
Trials Enter the number of pings that must remain unanswered for the
host to be regarded as unavailable.
Possible values: 1 ... 65536.
The default value is 3.
Controlled interfaces Select the interface(s) for which the action defined in Interface
Action is to be performed.
All physical and virtual interfaces can be selected.
Each interface, select whether each interface is to be activated (
Enable) or deactivated ( Disable, default value).
Funkwerk Enterprise Communications GmbH
16 Local services
bintec W1002/W1002n/W2002/WIx040/WIx065 319
