Field Description
ent is logged in.
Tx Packets Shows the total number of packets sent.
Rx Packets Shows the total number of packets received.
Signal dBm Shows the received signal strength in dBm.
Noise dBm Shows the received noise strength in dBm.
Data Rate Mbps Shows the current transmission rate of data received by this cli-
ent in Mbit/s.
The following transmission rates are possible: IEEE 802.11b:
11, 5.5, 2 and 1 mbit; IEEE 802.11g/a: 54,48,36,24,18,12,9,6
mbit.
If the 5 GHz frequency band is used, the display of 11, 5.5, 2
and 1 mbit is suppressed for IEEE 802.11b.
VSS - Details for Connected Clients
In the Monitoring->WLAN->VSS-><Connected client>-> menu, the current values and
activities of a connected client are shown.
Fig. 169: Monitoring->WLAN->VSS-><Connected client>->
Funkwerk Enterprise Communications GmbH
19 Monitoring
bintec W1002/W1002n/W2002/WIx040/WIx065 363
