FUTABA T10J - ThrottleNeedle Mixing

103
Airplane
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
This function is used when the engine is
equipped with a mixture control system (needle
control and other mixture adjustments to the
engine).
The throttle control servo connects to receiver
CH8.
●The mixture can be set by 5 point curve in relation
to the throttle stick.
●An acceleration function which accelerates the
engine to the optimal mixture when the throttle is
opened can be set.
"THR → NEEDL"
THR → NEEDL
Throttle → Needle mixing
(ACROBATIC)
■ Activating the function
＋ －
or
① Select the "MIX"
item and then
select the "ON"
by pressing the
+ key or – key.
● When you do not use a function, set
to the "INH" side.
■ 5 point curve setting
② Select the setting item (P-1 〜 P-5) and then set the
travel of each point by pressing the + key or – key.
Range：0 ～ 100%
Default：P-1:0%, P-2:25%, P-3:50%,
P-4:75%, P-5:100%
■ Acceleration rate
③ Select the "ACC" item and adjust the acceleration
amount by pressing the + key or – key.
Range：0 ～ 100%, Default：0%
● When you want to return the set value to
the initial value, press the + key and – key
simultaneously.
Throttle curve
● Select the setting item
with the Jog key.
Activating the function
5 Point curve set
（Cursor moves with a
THR stick）
Acceleration rate
● When not using this function,
select INH.
● The set-up curve is shown
NOTE：This cannot be used if Ailevator function
is active as they cannot be used simultaneously.
“AILVATOR mix “ON” “is displayed on the screen. Set the
THR → NEEDL function to ACT after setting the active
function to INH.
THR → NEEDL
