FUTABA T10J Manual

153
Glider
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL 2AIL+1F 2AIL+2F 2AIL+4FWING TYPE
This function is dedicated mixing for switching
the gyro sensitivity and gyro mode (AVCS/
NORMAL) of Futaba airplane use gyros. Up to 3
axes can be set.
●The sensitivity switch can be selected and the
sensitivity of each direction of the switch can be
set. (Switches A to H) If the airplane stalls during
flight, the gyro will lose control of the plane’s
attitude. From the standpoint of safety, we
recommend that the OFF (0%) position also be set
using a 3 position switch.
●CH5, CH5/CH7, CH5/CH8 or CH5/CH7/CH8
combinations can be selected as the sensitivity
setting channel.
"GYRO SENS"
GYRO SENS
Gyro sensor
(GLIDER)
■ Activating the function
＋ －
or
① Select the "MIX" item
and then select the
"ON" by pressing the +
key or – key.
● When you do not use a function, set to the
"INH" side.
■ Sensitivity switch selection
② Select the "SW" item and then select the
switch by pressing the + key or – key.
Range：SwA ～ SwH、Default：SwA
■ Sensitivity setting channel selection
＋ －
or
③ Select the
"CH" item and
then select
the sensitivity
setting channel by pressing the + key
or – key.
Range：CH5、CH5/CH7、
CH5/CH8、CH5/CH7/CH8
Default：CH5
■ Gyro type and sensitivity setting
④ Press the Jog key and select the sensitivity setting
screen you want to set and then set "type" (gyro type)
and "rate" (gyro sensitivity) of each channel by pressing
the + key or – key.
（"type"）Range：STD,GY Default：STD
（"rate"）Range：0 ～ 100%（STD）, NOR100 ～ 0 ～
AVC100%（GY） Default：50%（STD）, 0%（GY）
● When you want to return the set value to the initial
value, press the + key and – key simultaneously.
GYRO SENS
Activating the function
Gain Channel selection
Switch direction
Gyrotype,
Gain rate
● When not using this function,
select INH.
Sensitivity switch selection
（Current switch operating
direction）
● Switches to the sensitivity setting
screen of each switch
direction when the
Jog key is pressed.
● Select the setting item
with the Jog key.
（Gyro type） （Gyro Gain）
● When using a Futaba GYA gyro, select gyro type GY. This switches the gyro sensitivity setting
item to mode and sensitivity direct reading display.
＋ －
or
GYRO SENS
