FUTABA T10J Manual

152
Glider
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL 2AIL+1F 2AIL+2F 2AIL+4FWING TYPE
This mixing is used with V tail aircraft that
combine the elevator and rudder functions.
"V-TAIL"
V-TAIL
V-Tail
(GLIDER)
CH2 Servo CH4 Servo
Elevator ELE1 ELE2
Rudder RUD2 RUD1
Activating the function
ELE1 rate
ELE2 rate
RUD2 rate
RUD1 rate
● When INH is selected, the
function cannot be used. To use
the function, select ACT.
（Rate adjustment）
● Select the setting item with
the Jog key.
■ Activating the function
① Select the "MIX" item and then
select the "ACT" by pressing
the + key or – key.
＋ －
or
● When you do not use a
function, set to the "INH" side.
■ Rate adjustment
＋ －
or
② Select the "RATE" item and then adjust
the mixing rate by pressing the + key or
– key.
Range：-100 ～ +100%
Default：+50%
（only ELE2 : -50%）
● When you want to return the set value to the initial value, press
the + key and – key simultaneously.However, polarity does not
return.
NOTE：We recommend that setting be performed while moving the stick and checking the amount of movement. If
the amount of movement is too large, elevator and rudder operation will be compounded and the servo travel range
will be exceeded and a dead band in which the servo will not operate may be created.
V-TAIL
CH2 (CH4)
CH4 (CH2)
Ｖ-tail
V-TAIL
