160
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL 2AIL+1F 2AIL+2F 2AIL+4FWING TYPE
"CAMBR MIX"
CAMBR MIX
Camber mixing
(GLIDER)
● Select the setting item
with the Jog key.
● The number is changed
by + key or – key.
● Amount of compensation
of the elevator when the
camber changed.
● Flap1
● Aileron1
● Camber MIX ACT/INH
Sets the amount of
movement when
the VR was turned.
Sets the amount of
movement when
the VR is turned.
● Flap2
● Aileron2
● Can be set to operate
from a switch. When
NULL, it is operated by
a VR.
● Flap3
● Flap4
● Elevator
[Camber FLP ２page]
（Currently selected condition）
（Currently selected condition）
CAMBR MIX (NORM) 1 2
(RATE1) (RATE2)
AIL1 ▶ 0 ▶ 0
AIL2 ▶ 0 ▶ 0
MIX ▶ INH
SW ▶ SwA ▶ DOWN
CAMBR MIX (NORM) 1 2
(RATE1) (RATE2)
FLP1 ▶ 0 ▶ 0
FLP2 ▶ 0 ▶ 0
FLP3 ▶ 0 ▶ 0
FLP4 ▶ 0 ▶ 0
＋ －
All the wing control surfaces are
lowered and the camber is increased
(lift increases)
Attitude changes are compen-
sated for by setting the
amount of elevator movement.
Attitude changes are compen-
sated for by setting the
amount of elevator movement.
Turn the VR
All the wing control surfaces are
raised and the camber is
decreased (lift decreases)
This function adjusts the rate of camber
operation for the wing camber (ailerons, camber
flaps, brake flaps) in the negative and positive
directions. The aileron, flap, and elevator rates
can also be adjusted independently and attitude
changes caused by camber operation can be
corrected.
*Initial setting assigns camber operation to side lever DT6.
● Operation can be turned on and off by switch
● VR can be changed by AUX channel 10
(RATE1)：The amount of
operations when VR is turned to
the right.
(RATE2)：The amount of
operations when VR is turned to
the left.
