168
MENU 1 2
▶MDL-SEL
▶MDL-NAME
▶FAIL SAFE
▶REVERSE
▶TIMER
▶SERVO
▶END POINT
▶TRIM
▶SUB TRIM
▶P.MIX1-6
▶AUX-CHAN
▶PARAMETER
MENU 1 2
▶TELEMETRY
▶SENSOR
▶SBUS LINK
▶MDL-TRANS
▶TRAINER
▶CNTR ALRM
▶D/R,EXPO
▶GYRO SENS
（1 second）
＋
END
Multicopter Function
MENU
● When the + key is pressed for
1 second, the menu screen is
displayed.
● When the END key i s
pressed, the display returns
to the home screen.
● First set the
throttle to slow.
● Then turn on the
power.
MENU
1/2
MENU
2/2
（Home screen）
Power ON
（Selection）
● Move the cursor
(highlighted) up and down
and to the left and right
with the Jog key and select
the function.
The cursor can be moved
over several pages.
（Calling the setting screen）
● Press the Jog key to open the
setting screen.
To menu screen
by holding down
the + key
The setting screen of each function is called from the following menu. The function when
the model type was set to multicopter (MULTI COPT) is displayed here.
To Next Page
