167
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL 2AIL+1F 2AIL+2F 2AIL+4FWING TYPE
This function shifts the ailerons, elevators, and
each ap trim to the preset position by means of a
switch.
●The servo speed at which trim is to the set position
can be set.
"TRIM MIX"
TRIM MIX
Trim mix
(GLIDER)
● Select the setting item
with the Jog key.
● The ON/OFF switch can be changed.
(Selected with the Jog key and
changed with the +key)
● Sets the ON/OFF direction of the
selected switch.
● When condition is used, the display
can be switched and each connection
can be set by switching the condition
switch.
Trim of each control surface is
moved to the set value.
● Sets the trim neutral position of each
control surface.
Range：-100 ～ +100
Returned to 0 by pressing the + key
and – key simultaneously.
ON
ON
ON
ON
OFF
OFF
ON
ON
OFF
ON
ON
OFF
ON ON
OFF
OFF
ON
OFF
ON
OFF
OFF
NULL UP UP&DWN UP&CNT CENTER CNT&DN DOWN
3 Position Switch
ON
ON
OFF
NULL UP DOWN
2
Position Switch
Elevator
(CH2)
ON
OFF
Set the switch to ON
Aileron1
(CH1)
Aileron2
(CH7)
Flap4
(Brake Flap)
(CH9)
Flap3
(Brake Flap)
(CH8)
Flap2
(Camber Flap)
(CH6)
Flap1
(Camber Flap)
(CH5)
TRIM MIX 1 2
MIX▶ INH
SW▶ SwA ▶ DOWN
AIL ▶ OFF
FLP ▶ OFF
ELE ▶ OFF
DELAY
Activating the function
● When not using this
function, select INH.
● Servo speed at which the trim position is to the set
position. Sudden attitude changes are prevented
by turning the switch on. (Selected by Jog key and
changed by + key and – key.)
Range：OFF(fast shift）、1 ～ 10（slow shift）
Returned to OFF by pressing the Jog key for a long
time.
*This is not the servo speed when the stick was
operated.
TRIM MIX (NORM) 1 2
FLP1 ▶ 0
FLP2 ▶ 0
FLP3 ▶ 0
FLP4 ▶ 0
AIL1 ▶ 0
AIL2 ▶ 0
ELE ▶ 0
[TRIM MIX page1]
[TRIM MIX page2]
● The number is changed
by + key or – key.
＋ －
To Next Page
