FUTABA T10J - Aileron Differential

97
Airplane
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
"AIL-DIFF"
AIL-DIFF
Aileron di󱐯erential
(ACROBATIC)
■ Activating the function
① Select the "MIX" item and then
select the "ACT" by pressing
the + key or – key.
＋ －
or
● When you do not use a
function, set to the "INH"
side.
■ Aileron rate
＋ －
or
② Select the "RATE-AIL1" item and move
the aileron stick to the left and right
and adjust the travel of each servo by
pressing the + key or – key.
Range：-120 ～ +120%
Default：+100%
● When you want to return to the initial value, press the + key
and – key simultaneously. However, when the polarity is
changed only the number returns to the initial value.
（Adjust the "RATE-AIL2" item in the same way as ② .）
Aileron Di󱐯erential
NOTE：Aileron Differential cannot be used simultaneously with Flaperon or Elevon. If
another function is already active, “Others WING mix “ON” is displayed on the screen. After
setting the active function to “INH” , set the Aileron Di󱐯erential function to “ACT” .
ACT/INH
Aileron1（CH1）rate
Aileron2（CH7）rate
● When INH is selected, the
function cannot be used. To use
the function, select ACT.
（Aileron）
L：Aileron stick Left side rate
R：Aileron stick Right side rate
● Select the setting item with
the Jog key.
CH1
CH7
The left and right aileron differential can be
adjusted independently. This function is restricted
to 2 servo aileron.
AIL-DIFF
