3
Introduction ............................................6
●Support and Service ..................................6
●Application, Export, and Modication ....7
●Denitions of Symbols ...............................8
●Safety Precautions (do not operate without
reading) .......................................................9
Before use ..............................................12
●Features of 10J ........................................12
●Contents and technical specications ....13
●System compatibilty ................................13
●Accessories ................................................14
●Transmitter controls ................................15
Battery ............................................................. 17
Switch ............................................................. 18
To turn on the 10J ......................................... 18
Receiver and servo connections .................... 19
Charging the batteries ................................... 22
Stick adjustment ............................................. 23
Adjusting display contrast ............................. 24
Connector/Plug ............................................... 24
Transmitter displays & buttons .................... 25
Warning & error displays.............................. 26
Link procedure ............................................... 27
●Receiver nomenclature ............................28
●R3008SB CH mode ..................................29
●Receiver's antenna installation ............... 30
●Mounting the servo .................................. 31
●Range check the radio .............................32
●S.BUS/S.BUS2 Installation .....................33
●S.BUS Wiring example ............................34
●S.BUS2 System .........................................35
●S.BUS/S.BUS2 Device setting .................36
●Telemetry System ..................................... 37
TABLE OF CONTENTS
INTRODUC-
TION
AIRPLANE
HELICOPTER
GLIDER
MULTICOPTER
BEFORE USE
COMMON
TX SETTING

Table of Contents
