FUTABA T10J - PIT-Curve

118
Airplane
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
This function is a function for the variable pitch
propellers of an airplane.
The curve of ve points can be set up.
●PIT-curve function cannot be used when an
AILVATOR function is ACT.
●CH of a pitch can be set to 8CH or 5CH.
"PIT-CURVE"
PIT-CURVE
Pitch curve（Airplane）
(ACROBATIC)
■ Activating the function
＋ －
or
① Select the "MIX" item
and then select the
"ON" by pressing the +
key or – key.
● When you do not use a function, set to the
"INH" side.
■ Switch selection
＋ －
or
② Select the "SW" item
and then select the
switch by pressing the
+ key or – key.
Range：SwA ～ SwH、Default：SwE
■ 5 point curve set
＋ －
or
③ By Jog key, either of P-1
to P-5 is chosen. The +
key or - key is pressed
and a rate is set up.
Range：-100 ～
+100%
Default：P-1:-100%, P-2:-50%, P-3:0%,
P-4:+50%, P-5:+100%
（When a channel is changed）
■ Channel selection
＋ －
or
① Select the "CH" item and
then select the channel
by pressing the + key or –
key.
Range：8CH、5CH
Default：8CH
PIT-curve
Activating the function
Switch selection
5 point curve
set
● Select the setting item
with the Jog key.
● When not using this function,
select INH.
Channel selection
● The set-up curve is shown
（Present switch position）
PIT-CURVE
