FUTABA T10J - Trim

51
Common function
Function
Method
① Call the menu screen from the
home screen by pressing the + key
for 1 second.
＋
② Select
from the menu with the Jog
key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
① Select the RESET item and press the Jog key for 1 second.
（1 second）
● A "beep" sounds to indicate that resetting is
complete. At this time, the trim position number
returns to 0.
Trim reset
① Select the trim you want to set from the STEP item
and set the step size by pressing the + key or – key.
＋ －
or
Range：1〜40
Default：4
● When you want to return the
set value to the initial value,
press the + key and – key
simultaneously.
Trim step
Trim Reset
This function returns the trim of the model
memory in use to the center (initial state).
However, at this time, sub trim and trim step
amount are not reset.
Trim Step
The amount of trim change per step can be
changed between 1 and 40 according to the aircraft
capacity and trim application.
Set it to match the application. With ordinary
aircraft, a setting of about 2 to 10 should be fine.
(Initial value: 4)
● For example, when the step size is
the initial value (4), trim movement
from center to end is 30 steps. If the
step size is made 40, the trim moves 3
steps.
"TRIM"
Trim Reset
Trim step
● Select the item with the
Jog key.
● The numbers in ( ) indicate
the current trim position. (The
trim operating range is 120 〜
100[DT5,DT6]）
（Trim step rate）
TRIM
Trim reset ／ Trim step
(Common)
TRIM
