FUTABA T10J Manual

120
Helicopter
（1 second）
＋
END
MENU 1 2 3
▶MDL-SEL
▶MDL-NAME
▶FAIL SAFE
▶REVERSE
▶TIMER
▶SERVO
▶END POINT
▶TRIM
▶SUB TRIM
▶P.MIX1-6
▶AUX-CHAN
▶PARAMETER
MENU 1 2 3
▶TELEMETRY
▶SENSOR
▶SBUS LINK
▶MDL-TRANS
▶TRAINER
▶CONDITION
▶SWH.MIX
▶SWASH AFR
▶SWH.RING
▶OFFSET
▶DELAY
▶THR.CUT
MENU 1 2 3
▶GYRO SENS
▶D/R,EXPO
▶THR-CURVE
▶PIT-CURVE
▶REVO.MIX
▶THR HOLD
▶GOVERNOR
▶HOV-THR
▶HOV-PIT
▶HI ／ LO-PIT
▶THR-MIX
▶THR→NEEDL
HELICOPTER Function
The setting screen of each function is called from the following menu. The function when
the model type was set to helicopter is displayed here.
MENU
● When the + key is pressed for
1 second, the menu screen is
displayed.
● When the END key is
pressed, the display
returns to the home
screen.
MENU
1/3
MENU
2/3
MENU
3/3
（Home screen）
PowerON
● First set the
throttle to slow.
● Then turn on the power.
（Selection）
● Move the cursor
(highlighted) up and
down and to the left and
right with the Jog key and
select the function.
The cursor can be moved
over several pages.
（Calling the setting screen）
● Press the Jog key to open the
setting screen.
To menu screen
by holding down
the + key

FUTABA T10J Specifications

General

Channels	10
Frequency	2.4GHz
Model Memory	30
Display	LCD
Telemetry	Yes
Weight	590g
Trainer Port	Yes
Modulation	S-FHSS
Power Supply	6V to 7.4V (2S LiPo)
