FUTABA T10J Manual

145
Helicopter
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
The high/low pitch trim function adjusts the
pitch servo high side and low side to the optimum
pitch individually for each ight condition (normal,
idle up 1/2/3, hold).
●The high pitch and low pitch trim levers and
operating direction can be selected. The trim
levers operate in common for each condition and
a use/do not use trim lever can be selected for
each function.
"HI/LO-PIT"
HI/LO-PIT
HI/LO-pitch trim
(HELICOPTER)
■ Selection of condition
＋ －
or
① Select the setting
condition selection
item and select
the condition by
pressing the + key or – key.
■
DT, VR adjustment ON, OFF selection
② Select ON, OFF by pressing the + key or
– key at the high side or low side "ADJ"
item.
■ TYP selection
③
Select trim or VR by pressing the + key or –
key at the "TYP" item.
Range：+DT5, -DT5, +DT6, -DT6,+VR,
-VR
● The high side or low side pitch can be
adjusted with the selected digital trim or
VR.
■ Adjustment by Key operation
④
Select each function item of "HI-PIT" or "LO-PIT" and
set the pitch rate by pressing the + key or – key.
Range：60 ～ 100%
Default：100%
HI/LO-pitch trim
Selection of condition
High side Pitch
Trim ON,OFF
High side trim
（Low side same）
（Present condition ）
（Actual adjustment position
including high pitch trim）
● Selected from among DT5,
DT6, and VR. The operation
direction is different
depending on the polarity (+,
-).
● Select the setting item
with the Jog key.
HI/LO-PIT
