FUTABA T10J Manual

106
Airplane
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
This mixing function mixes two ailerons and also gives the
ailerons a ap function. Aileron and left and right aileron control
surfaces can be raised at the same time. If this function is used
together with air brake function, the aircraft speed can be dropped
when landing and is effective in narrow places. Connect the left
aileron servo to CH1 (AIL) and the right aileron servo to CH6
(FLP).
●The up and down angle of the left and right aileron control
surfaces can be adjusted individually.
●The left and right ap travel can also be adjusted individually.
"FLAPERON"
FLAPERON
Flaperon
(ACROBATIC)
CH6 servo CH1 servo
Aileron
Operation
Right Aileron Left Aileron
Flap Operation Flap1 Flap2
Activating the function
Aileron1（CH1）rate
Aileron2（CH6）rate
Flap2（CH1）rate
Flap1（CH6）rate
● When INH is selected, the
function cannot be used. To use
the function, select ACT.
（Aileron rate）
L：Aileron stick Left side rate
R：Aileron stick Right side rate
（Flap rate）
● Select the setting item with
the Jog key.
CH1
CH6
NOTE：Only the Flaperon, AileronDi󱐯erential, or Elevon functions can
be used. They cannot be turned on simultaneously. When another
function is already activated, “Other WING mix “ON” “is displayed on the
screen. Set the Flaperon function to ACT after setting the active function
to INH.
FLAPERON

FUTABA T10J Specifications

General

Channels	10
Frequency	2.4GHz
Model Memory	30
Display	LCD
Telemetry	Yes
Weight	590g
Trainer Port	Yes
Modulation	S-FHSS
Power Supply	6V to 7.4V (2S LiPo)
