FUTABA T10J Manual

107
Airplane
■ Activating the function
① Select the "MIX" item and then
select the "ACT" by pressing
the + key or – key.
＋ －
or
● When you do not use a
function, set to the "INH" side.
■ Aileron rate
＋ －
or
② Select "RATE-AIL1" and operate the
aileron stick to the left and right and
adjust the travel of each servo by
pressing the + key or – key.
Range：-120 ～ +120%
Default：100%
● When you want to return the set value to the initial value,
press the + key and – key simultaneously. However, when
the polarity is changed, only the number is returned to the
initial value.
(The “RATE-AIL 2” item is adjusted in the same way as ② .）
（When ap trim is used, make the settings shown below.）
● However, set the basic travel with the Flap function in advance.（Default：0%）
■ Flap rate
＋ －
or
③ Select the "RATE-FLP2" item and adjust
the Flap2 travel by pressing the + key or
– key.
Range：-120 ～ +120%
Default：+100%
● When you want to return the set value to the initial value, press
the + key and – key simultaneously.However, polarity does not
return.
（The “RATE-FLP1” item is adjusted in the same way as ③ .
However, the “RATE-FLP1” side initial value is -100%.）
Flaperon
CH1
CH1
CH6
CH6
When flaperon is active, the
ailerons can be controlled by the
servos connected to CH1 and CH6.
The servo travel can be adjusted
by the left and right end points.
The left and right ailerons can
be raised (brake operation) and
lowered (flap operation) at the
same time by setting SW-C to its
lowest position.
Flaperon ACT
Air brake ACT

FUTABA T10J Specifications

General

Channels	10
Frequency	2.4GHz
Model Memory	30
Display	LCD
Telemetry	Yes
Weight	590g
Trainer Port	Yes
Modulation	S-FHSS
Power Supply	6V to 7.4V (2S LiPo)
