FUTABA T10J - FlapElevator Mixing

110
Airplane
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
■ Activating the function
① Select the "MIX" item and then select
the "ON" by pressing the + key or –
key.
＋ －
or
● When you do not use a function, set
to the "INH" side.
■ Mixing rate
＋ －
or
② Select the "RATE" item and
then adjust the mixing rate by
pressing the + key or – key.
Range：-100 ～ +100%
Default：0%
● When you want to return the set value to the initial
value, press the + key and – key simultaneously.
（When changing the mixing reference point）
■ Mixing reference point o󱐯set setting
（1 second）
① Select the "OFFSET" item and turn the Flap knob to the
point you want to make the mixing reference point and
set the reference point by pressing the Jog key for 1
second.
Range：-100 ～ +100% Default：0%
Flap → ElevatorMixing
This mixing is used to compensate for pitch
changes (elevator direction) at ap operation.
●When the mixing direction is reversed by the
linkage adjustment is possible by changing the
rate polarity.
●The mixing reference point can be shifted. (OFFSET)
"FLAP → ELE"
FLAP → ELE
Flap → Elevator mixing
(ACROBATIC)
Activating the function
Mixing rate
Mixing o󱐯set rate
● When not using this function,
select INH.
（Present flap operating
position）
● Select the setting item
with the Jog key.
FLAP → ELE
