FUTABA T10J - Aileron Differential

150
Glider
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL 2AIL+1F 2AIL+2F 2AIL+4FWING TYPE
Two servos can be used for ailerons and a
differential can be applied to left and right
aileron operation.
Connect the left aileron to CH1 (AIL) and the
right aileron to CH7.
●The up and down angle of the left and right aileron
control surface can be adjusted individually.
"AIL-DIFF"
AIL-DIFF
Aileron di󱐯erential
(GLIDER)
■ Aileron control surface angle adjustment
① Select the "RATE-AIL1" item and then move the aileron stick
to the left and right and adjust the travel of each by pressing
the + key or – key.
Range：-120 ～ +120%
Default：+100%
● When you want to return the set value to the initial value, press
the + key and – key simultaneously.However, polarity does not
return.
（Adjust the RATE-AIL2 item the same as ② .）
Aileron Di󱐯erential
Aileron1（CH1）rate
Aileron2（CH7）rate
（Aileron rate）
L：Aileron Stick Left side rate
R：Aileron Stick Right side rate
● Select the setting item with
the Jog key.
CH1
CH7
AIL-DIFF
