FUTABA T10J - ElevatorFlap Mixing

111
Airplane
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
■ Activating the function
＋ －
or
① Select the "MIX" item
and then select the ON
or OFF by pressing the
+ key or – key.
● When you do not use a function, set to the
"INH" side.
■ Switch selection
＋ －
or
② Select the "SW" item
and then select the
switch by pressing the
+ key or – key.
Range：SwA ～ SwH、Default：SwC
■ Switch direction
＋ －
or
③ Select the "POSI
" by pressing the
+ key or – key at
the ON direction
selection item.
Range：
● 2P SW：NULL, UP, DOWN
● 3P SW：NULL, UP, UP&D, UP&C,
CNTR, C&DN, DOWN
■ Mixing rate
＋ －
or
④ Select the "RATE" item and
then adjust the mixing rate by
pressing the + key or – key.
Range：-100 ～ +100% Default：+50%
● When you want to return the set value to the initial
value, press the + key and – key simultaneously.
However, polarity does not return.
● RATE↑/↓ cursor position operates and chooses an
elevator stick.
Elevator → FlapMixing
● This cursor position
operates and chooses an
elevator stick.
This mixing is used when you want to apply mixing from elevators
to aps. Usually, mixing is such that the aps are lowered by raising
the elevators. When used with Fun Fly and other aircraft, small loops
are possible.
●The up side and down side rates can be adjusted.
"ELE → FLAP"
ELE → FLAP
Elevator → Flap mixing
(ACROBATIC)
Activating the function
Mixing rate
Switch selection
Switch direction
● When not using this Function
select INH. The display of On/
O󱐯 is shown when active and
assigned to a switch.
（Elevator down side rate）
（Elevator up side rate）
● Select the setting item
with the Jog key.
Flap CH6
Elevator CH2
● Sets the ON/OFF direction of the selected switch.
○ 2P SW：NULL, UP, DOWN
○ 3P SW：NULL, UP, UP&D, UP&C, CNTR, C&DN, DOWN
ELE → FLAP
