FUTABA T10J - Sensor:manually Assigning a Sensor

88
Common function
A slot number can be assigned without connecting the sensor to the transmitter. In a manual set, it is
required to store a start slot number in a sensor.
● Manually assigning a sensor slot number
SENSOR SLOT 1 2 3 4 5 6
1▶ SBS-01T *****
3▶ SBS-01A *****
4 SBS-01A
5 SBS-01A
6▶ SBS-01V *****
2▶ SBS-01RM/O *****
① Call the menu screen from the
home screen by pressing the + key
for 1 second.
＋
② Select ③ Open the setting screen by
pressing the Jog key.
（1 second）
SENSOR SLOT 1 2 3 4 5 6
13 SBS-01G
15 SBS-01G
16 INHIBIT
17 INHIBIT
18 INHIBIT
14 SBS-01G
from the menu with the
Jog key.
④ Jog key is pressed in a side and it
searches for an empty slot. (INHIBIT).
"SENSOR"
Calling the setting screen
① When an INHIBIT slot is selected
and the Jog key is pressed, a list
of sensors that can be assigned to
that slot is displayed.
*Refer to the <Assignable slots>
table.
② Select the sensor you want to
assign and press the Jog key.
③ Press the END key.
Assignment of slot
END
