104
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
D/R
The aileron, elevator and rudder channel control surface angle can be switched in 2 steps
●The control surface angle is adjusted by each direction of the switch. The left and right (up and down)
direction of each switch can be set individually.
EXP
This function makes operation more pleasant by changing the operating curve so that servo movement
is sluggish or sensitive relative to stick operation near the aileron, elevator, throttle, and rudder neutral
position. Adjustments can be made in 2 steps according to the control surface angle.
●The “-” side makes servo movement sluggish and the “+” side makes servo movement sensitive near the
neutral position. Exponential is applied to entire throttle servo travel. When the “+” side is increased, the
slow side becomes sluggish and the high side becomes sensitive.
●Setting corresponding to each rate of dual rate (D/R) is possible. (Except throttle) The direction of each
switch and the left and right (up and down) direction of each channel can be set individually.
Switch selection（SW）
Switches A to H can be selected as the aileron channel, elevator channel, and rudder channel dual rate
(exponential) switch.
●Default
：
Aileron
：
SwitchD
／
Elevator
：
SwitchA
／
Rudder
：
SwitchB
"D/R,EXPO"
D/R,EXPO
Dual rate ／ EXPO
(ACROBATIC)
Channel selection
Dual rate
EXPO
Switch selection
● The channel under selection is
underlined.
（Switch Direction）
● The dual rate and exponential
settings are displayed by a
curve.
● Channel selection/Select
the setting item with the
Jog key.
＜ Channel ＞
1：Aileron
2：Elevator
3：Throttle
4：Rudder
（Switch No.）
（D/R and EXPO rate display）
Top row；Left side ／ down
Bottom row；Right side ／ up
To Next Page
