FUTABA T10J Manual

Before use
23
ADJUSTING THE LENGTH OF THE CONTROL STICKS
STICK LEVER TENSION ADJUSTMENT
You may adjust the tension of your sticks to provide the feel that you prefer for ying. To adjust
your springs, you’ll have to remove the rear case of the transmitter. First, remove the battery
cover on the rear of the transmitter. Next, unplug the battery wire, and remove the battery from
the transmitter. Next, using a screwdriver, remove the four screws that hold the transmitter’s rear
cover in position, and put them in a safe place. Gently ease off the transmitter’s rear cover. Now
you’ll see the view shown in the gure above.
Using a small Phillips screwdriver, rotate the adjusting screw for each stick for the desired spring
tension. The tension increases when the adjusting screw is turned clockwise. When you are
satised with the spring tensions, reattach the transmitter's rear cover. When the cover is properly
in place, reinstall and tighten the four screws. Reinstall the battery and cover.
You may change the length of the control sticks to make
your transmitter more comfortable to hold and operate. To
lengthen or shorten your transmitter’s sticks, first unlock
the stick tip by holding locking piece B and turning stick
tip A counterclockwise. Next, move the locking piece B
up or down (to lengthen or shorten). When the length feels
comfortable, lock the position by turning locking piece B
counterclockwise.
Stick tip A Locking piece B
Mode 2 transmitter with rear case removed.
Aileron
Elevator
Rudder
StickStick
Four screws are
removed and rear
case is removed.
+ screw is clockwise.
Stick tension maximum Stick tension minimum
+ screw is counter-clockwise.
Do not loosen
the screw past
the top of the
frame, as this
will cause the
screw to rub on
the back case.
※
A screw touches a case.

FUTABA T10J Specifications

General

Channels	10
Frequency	2.4GHz
Model Memory	30
Display	LCD
Telemetry	Yes
Weight	590g
Trainer Port	Yes
Modulation	S-FHSS
Power Supply	6V to 7.4V (2S LiPo)
