92
Common function
Function
Method
① Call the menu screen from the
home screen by pressing the + key
for 1 second.
＋
② Select
from the menu with the Jog
key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
Transmission of model data is possible with
T10J transmitters. Data transfer is performed by
the radio. The MDL-TRANS function works with
the current model you are using in the transmitter.
As for the receiving transmitter, any data on the
current model that is receiving the information will
be over-written.
"MDL-TRANS"
MDL-TRANS
Model transfer
(Common)
●
MDL-TRANS between two T10J radios should be performed within 2-meter range.
① In each T10J, the ＋ or － key is pressed and it is
made "TRANSFER" and "RECEIVE".
＋ －
or
● "TRANSFER"：T10J of data origin
"RECEIVE"：T10J which receives data
Selection range：TRANSFER, RECEIVE
② Select "Execute" with the Jog key.
③ Hold down the Jog key [ each T10J ].
（1 second )
）
● "COMPLETE" is displayed and the mode
transfer is nished.
Model transfer
● If data is not being transmitted, the receiving transmitter
returns to normal operation 10 seconds after execution. At
this time, "Failure" (not transmitting) is displayed.
● From T8J to T10J, data transfer is possible. In that case, TYPE
of T10J on the "RECEIVER" side is changed into "T8J" by ＋－
key. However, data cannot be sent to T8J from T10J.
Always check servo direction prior to every
flight as an additional precaution to confirm
proper model date, hook ups, and radio function.
NOTE:
MDL-TRANS between two T10J radios should
be performed within a 2-meter range.
MODE：
TRANSFER（T10J of data
origin ）／
RECEIVE（T10J which
receives data）
Execution of transmission/
reception
*T10J does not carry out normal operation during data transfer.
