The timer is convenient during a competition to
set the specied amount of time or the ying time
on a full tank of fuel.
●Two timer systems can be set. Timer 1 <TMR1> and
Timer 2 <TMR2>
●The timers can be set for each model. Since the
timers can be set to match the model, they do not
have to be reset each time the model is changed
●The type of timer can be selected from among
up (UP), down (DOWN), and down stop (DN-STP).
The up timer is counted up from 0 and the elapsed
time is displayed on the screen. The down timer is
counted down from the set time and the remaining
time is displayed on the screen. The down stop
timer stops the count at 0. Each timer can be set
up to 99 minutes 59 seconds.
●Switches A to H, throttle stick (ST-THR), or power
switch (PWR-SW) can be selected as the start/
stop switch (ON-SW). The ON/OFF direction can
also be set. However, when the power switch was
selected, the timer starts when the power switch is
turned on.
●When the timer you want to reset is selected
with the Jog key and the Jog key is pressed for
1 second at the home screen, the timer is reset.
Switches A to H can be selected as the reset switch
(RS-SW). The ON/OFF direction can also be set.
●The up/down timer audible alarm indicates the
time by a beep every second, continuous beeping
at 2 second intervals from 20 seconds before the
set time, and a continuous beeping at a 1 second
interval from 10 seconds before the set time.
"TIMER"
TIMER
Timer
(Common)
■ Mode selection
①
Select timer mode
from the "MODE"
with the
＋ or －key.
＋ －
or
（Range ／ Default）
UP, DOWN, DN-STP/UP
■ Timer time setting
② Set the time by
pressing the + key or
– key at each TIME
(minutes):(second)
item.
（Range ／ Default）
0 〜 99 minutes 59
seconds/10 minutes 00
second
■ Switch selection and ON direction setting
③ Select the switch by pressing the + key or – key at
the ON-SW or RS-SW item and set the ON direction by
pressing the + key or – key at the ON direction setting
item.
(Switch setting range/ Default )
ON-SW: SwA 〜 H, ST-THR, PWR-SW/SwA
RS-SW: SwA 〜 H/SwA
(Switch ON direction/ Default )
3P SW: NULL (normally o󱐯), UP, UP&DWN, UP&CNT, CENTER,
CNT&DN, DOWN/NULL
2P SW: NULL, UP, DOWN/NULL
Timer ＜TMR1＞＜TMR2＞
● Select the item with the
Jog key.
Time set up
Mode selection
ON Switch selection
Switch direction
Reset Switch selection
Switch direction
●
When the throttle switch is
selected at switch selection,
hold the throttle stick in the
position you want to set the
ON/OFF point at ON direction
setting and set the ON/OFF
position by pressing the Jog key
for 1 second. The timer is turned
ON at points higher than this
position. The ON direction can
be switched by pressing the +
key or – key.
（Timer1） （Timer2）
TIMER
