FUTABA T10J - Page 113

114
Airplane
■ Mode
① Select the "MODE" item and then select the
mode by pressing the + key or – key.
＋ －
or
Range：NOR, ESC
Default：NOR
● "NOR"：Engine plane
"ESC"：Electric motor plane
■ Activating the function
② Select the "MIX" item and then select the o󱐯
by pressing the + key or – key.
＋ －
or
● When you do not use a function, set to the
"INH" side.
■ Switch selection
③ Select the "SW" item and then select
the switch by pressing the + key or –
key.
＋ －
or
Range：SwA ～ SwH
Default：SwA
■ Switch direction
④ Select the "POSI" by pressing the + key or – key at
the ON direction selection item.
＋ －
or
Range：
● 2P SW：NULL, UP, DOWN
● 3P SW：NULL, UP, UP&D, UP&C, CNTR, C&DN,
DOWN
■ Cut Position rate
⑤ Select the "RATE" item and then select
the cht position by pressing the + key or
– key (motor stop).
＋ －
or
● It adjusts to the position where an engine
is cut.
Range：-30 ～ 0 ～ +30%
Default：0%
● When you want to return the set value
to the initial value, press the + key and –
key simultaneously.
（In the case of ESC ）
■ Function release Throttle Position
⑥ Select the "THR" item and then select the release
position by THR stick is lowered and Jog key is
pressed for 1 second.
● Set to a safe low throttle position.
Range：0 ～ 100%
Default：15%
Throttle Cut
