142
Helicopter
■ Activating the function（R.P.M CH
selection）
＋ －
or
① Select the "MIX" item
and then select the
"CH7""CH8" or "CH9" by
pressing the + key or –
key.
● When you do not use a function, set to the
"INH" side.
■ Switch selection
＋ －
or
② Select the "MODE"
item and then select
the switch by pressing
the + key or – key.
Range：Cond, SwA ～ SwH
■ R.P.M set
＋ －
or
ting
③ Select the "RATE" item
and then adjust the rate
by pressing the + key or –
key.
Range：0.0 ～ 100.0%
Default：
（Cond）
NORM=0.0%, IDL1=50.0%, IDL2=100.0%,
IDL3=100.0%, HOLD=0.0%
（2P Switch selection ）
UP=0.0%, DOWN=100.0%
（3P Switch selection）
UP=0.0%, CNTR=50.0%, DOWN=100.0%
（When using an ON/OFF switch）
*Select the OFF-CTRL item and then adjust the rate by pressing the + key or – key.
■ ON/OFF Switch selection
＋ －
or
① Select the "SW"
item and then
select the switch
by pressing the
+ key or – key.
Range：SwA ～ SwH
Default：SwA
■ Switch direction
＋ －
or
② Select the "POSI" by pressing
the + key or – key at the ON
direction selection item.
● 2P SW：UP, DOWN
● 3P SW：UP, UP&D, UP&C, CNTR, C&DN, DOWN
（When number of rotations goes up at the time of Throttlehold ）
*If the speed is increased at throttle hold, the governor and transmitter operating directions will not
coincide. In this case, match the operating directions by reversing the polarity of "CH8".
Governor mixing
What is a governor ？
A governor is made up of a set of sensors which
read the RPM of the helicopter’ s head, and a
control unit that automatically adjusts the throttle
setting to maintain a constant head speed
regardless of changes in pitch of blades, weather
conditions, etc. Governors are extremely popular in
competition helicopters due to the consistency
provided.
How does it help in helicopter setup? The
governor eliminates the need to spend large
amounts of time setting up throttle curves, as it
automatically adjusts the engine’ s RPM to
maintain the desired head speed.
