164
（ELE → Camber ）
ELE→CAMBR (NORM) 1 2
(RATE1) (RATE2)
AIL1 ▶ 0 ▶ 0
AIL2 ▶ 0 ▶ 0
MIX ▶ INH
SW ▶ SwA ▶ DOWN
RANGE▶ 0% ( 0%)
ELE→CAMBR (NORM) 1 2
(RATE1) (RATE2)
AIL1 ▶ 0 ▶ 0
AIL2 ▶ 0 ▶ 0
MIX ▶ INH
SW ▶ SwA ▶ DOWN
RANGE▶ 30% ( 30%)
● Setting that inhibits camber mixing near the elevator center position. Setting so
that camber mixing is performed only when the elevators were operated greatly
is possible.
RANGE setting
■ Setting state
① Select the "0%" item next to
RANGE with the Jog key.
Can be either up or down. When set
to down, the up side is also set by the
same amount.
When elevator operation exceeds the range,
the stick position is displayed and mixing is
performed.
● When a RANGE number is selected and the
Jog key is pressed for 1 second, RANGE is
reset to 0% and normal mixing is performed.
■ To setting value
② Move the elevator stick to the position you
want operation to begin.
■ Set value memorization
③ Press the Jog key for 1 second.
Hold the stick in
position.
●
When MIX is set to ACT, the
amount of MIX(s) according to
stick operation is displayed.
To Next Page
