RECEIVER AND SERVO CONNECTIONS
Receiver
Output and
Channel
Helicopter (
HELI
)
1 Aileron (cyclic roll)
2 Elevator (cyclic pitch)
3 Throttle
4 Rudder
5 Gyro
6 Pitch (collective pitch)
7 AUX/Governor
8 AUX/ELE2/Mixture control
9 AUX
10 AUX
(Swash Type)
(Normal linkage type)
H-1:each servo linked
to the swashplate
independently.
AIL：Aileron Servo
ELE：Elevator Servo
PIT：Pitch Servo
*When using 8 or more channels, use an S.BUS
function or use a second R3008SB and link
both to your transmitter.
