FUTABA T10J - Page 54

55
Common function
（Changing the mixing reference point）
（Including trim operation）
■ Mixing reference point setting
（1 second）
① Select the "OFFST" item and hold
the master side stick or knob in
the position you want to set and
set the new reference point by
pressing the Jog key.
Range：-100 〜 +100%
（THR only 0 〜 100%）
Default：0%
■ Trim ON/OFF setting
＋ －
or
① Select the "TRM" item
and select ON or OFF by
pressing the + key or – key.
Range：OFF、ON
Default：OFF
● When you do not want to include trim in
mixing select OFF.
At the end of setting, check that the mixing function is performed normally.
（P.MIX5 〜 6 set up screen）
● Select the item with the
Jog key.
5Point curve
setting
● The set curve is displayed on a
graph.
Function activation
Master CH select
Slave CH select
Switch selection
Switch ON direction
● When INH is selected, the
function cannot be used.
When ON or OFF is selected,
the function is activated. ON
and OFF changes are linked
to the switch.
Refer to the P.MIX1 〜 4 setting method described previously for settings other than the 5 point curve setting
described below.
■ 5point curve setting
＋ －
or
① Select the setting item (P-1 〜 P-5) of each point with the Jog key and set the amount of
movement of each point by pressing the + key or – key.
Range：-100 〜 +100%
Default：0%
At the end of setting, check that the mixing function is performed normally.
P.MIX5 〜 6
CAUTION
CAUTION
