73
EXT-VOLT
(ALARM) (VIB) (LIMIT)
DN▶INH ▶OFF ▶ 0.0V
SPEECH▶ INH SW▶ NULL
0.0V
MIN/MAX=
0.0V / 0.0V
The EXT- voltage can be heard verbally from the transmitter with a commercial earphone (3.5mm
plug). The speech function can be turned on and o with the specied switch.
Method
① Select "EXT-VOLT" from the
telemetry screen with the Jog key.
② Open the setting screen by
pressing the Jog key.
① In the EXT-VOLT screen state, select
(SPEECH) from the menu with the
Jog key.
② Select the "ACT" by pressing
the + key or – key.
① In the EXT-VOLT screen state, select
(SW) from the menu with the Jog
key.
In "NULL", a speech always turns on.
② Select the switch by pressing
the + key or – key.
Selection range：
NULL, SWA 〜 SWH
Calling the setting screen
Speech
Switch set
● Listening to the EXT-voltage by speech.
Speech ON/OFF Switch
selection
＋ －
or
＋ －
or
ON
2 Position 3 Position
OFF
ON
OFF
OFF
Speech
ACT / INH
To Next Page
