Alarmspecications
CARESCAPEONE
AlarmvolumesettingMaximumsoundpressurelevel
6
Level6correspondstothe
factorydefaultminimum
allowedsettingforvolume
level.
Highpriorityalarm:50dBA
Mediumpriorityalarm:44dBA
Lowpriorityalarm:41dBA
10
Highpriorityalarm:71dBA
Mediumpriorityalarm:66dBA
Lowpriorityalarm:65dBA
Audioalarmsoundtolerances
Tolerancesforsounds(totalpulsedurationwithriseandfalltimes)are:
●Time<1000ms:±5%
●Time≥1000ms:±250ms
●Frequencies:±5Hz
IECalarmtonesoundpatterns
PriorityCorrespondingsoundpattern
High
●Beep“C”(523Hz/100ms)Silence(100ms)
●Beep“F”(698Hz/100ms)Silence(100ms)
●Beep“G”(784Hz/100ms)Silence(300ms)
●Beep“A”(880Hz/100ms)Silence(100ms)
●Beep“B”(988Hz/100ms)Silence(1s)
●Beep“C”(523Hz/100ms)Silence(100ms)
●Beep“F”(698Hz/100ms)Silence(100ms)
●Beep“G”(784Hz/100ms)Silence(300ms)
●Beep“A”(880Hz/100ms)Silence(100ms)
●Beep“B”(988Hz/100ms)Silence(5s)
Medium
●Beep“C”(523Hz/200ms;Silence(200ms)
●Beep“G”(784Hz/200ms;Silence(200ms)
●Beep“B”(988Hz/200ms)Silence(19s)
Low
Beep“C”(523Hz/200ms)
Silenceis24.8sifLowPriorityAlarmToneissettoRepeat.
262CARESCAPEONE2094480-001
