Parameterspecications
●Lowperfusion(25to240bpm):±3bpmAdult,Pediatric,Infant,
Neonate
Nellcoraccuracy:
Saturationaccuracyvariesbysensortype.ContactMedtronic
forsensoraccuracyinformation.Adultspecicationsareshown
forOxiMaxMAXAandMAXNsensorswiththepulseoximeter.
NeonatespecicationsareshownforOxiMaxMAXNsensorswith
thepulseoximeter.
●Withoutmotion(20to250bpm):±3bpmAdult,±3bpm
Neonatal
●Lowperfusion(20to250bpm):±3bpmAdult,±3bpmNeonatal
●Withmotion(20to250bpm):±5bpmAdult,±5bpmNeonatal
PulseoximetrylowperfusionrangeGETruSignal:0.03to20%
Masimo:0.02to20%
Nellcor:0.03to20%
SignalstrengthindicationSignalstrengthisindicatedthroughthedisplayofasterisks(No
asterisk,*,**,or***).Threeasterisksindicategoodsignalquality
andnoasterisksindicatepoorsignalquality.Allwaveformsare
normalizedtottheallocateddisplayarea.
TheGETruSignalplethwaveformisnotnormalized.
TheMasimoplethwaveformisnotnormalized.
TheNellcorplethwaveformisnotnormalized.
SpO₂supplementalanalysisgraphs
AdditionalaccuracyinformationforNellcor
™
sensors
ThetableinformationprovidessupplementaldataanalysisforNellcorsensors’
measurementaccuracy.ThetablesareprovidedbyCovidien.
ThefollowingmodiedBland-AltmanplotsshowSpO
2
databysensortype.Each
individualsubjectisrepresentedbyauniquemarkerontheplots.Subjectidentication
numbersareindicatedinthelegendwitheachplot.
2094480-001CARESCAPEONE307
