Parameterspecications
DebrillatorsyncinputsignalSignalamplitudeof-2.0Vto-25.0Vor+2.0Vto+25.0Vfora
durationof2.5msandgreaterisdetectedasasynchronization
pulse
Debrillatorsyncoutputdelay
<35ms
Impedancerespirationstandardscompliance
TheCARESCAPEECGenclosureandinterfacecablearetreatedasTYPECF
DEFIBRILLATION-PROOFAPPLIEDPARTsperIEC60601-2-27Clause201.6.2.
CompatibleleadwiresareTYPECFDEFIBRILLATION-PROOFAPPLIEDPARTs.
Impedancerespirationperformance
specications
Impedancerespirationrate
measurementrange
0to200breaths/minute
Impedancerespirationmeasurement
accuracy
●0to120breathsperminute:±1breathperminute
●121to200breathsperminute:±3breathsperminute
Impedancerespirationrateresolution1breathperminute
Impedancerespirationinputimpedance
range
●Dynamic:0.4to10Ω
●Static:100to1500Ω@52.3kHz
Impedancerespirationnormalized
respirationsensingcurrent
<100µA
RMS
Impedancerespirationcarrierfrequency52.3kHz±5Hz
Impedancerespirationleadsavailable
I,II,RL-LL
Impedancerespirationwaveformsweep
speedoptions
0.625mm/s,6.25mm/s,12.5mm/s,25mm/s,50mm/s
SpO
2
standardscompliance
ThesystemwithCARESCAPESpO
2
complieswithISO80601-2-61:2011-04.
TheCARESCAPESpO
2
sensorinterfacecable,excludingthemodulestrainrelief,and
compatiblesensorsaretypeBFDEFIBRILLATION-PROOFAPPLIEDPARTSperISO
80601-2-61Clause201.6.
TheCARESCAPESpO
2
–Masimoenclosureandinterfacecable,excludingthe
connectorandstrainreliefonthehostendofthecable,istreatedasatypeBF
DEFIBRILLATION-PROOFAPPLIEDPART.CompatiblesensorinterfacecablesandSpO
2
sensorsaretypeBFDEFIBRILLATION-PROOFAPPLIEDPARTSperISO80601-2-61
Clause201.6.
TheCARESCAPESpO
2
–NellcorOxiCORModuleenclosureandcablefromthe
OxiCORmoduletothestrainreliefontheIsolationModulearetreatedastypeBF
DEFIBRILLATION-PROOFAPPLIEDPARTS.CompatibleSpO
2
sensorsaretypeBF
DEFIBRILLATION-PROOFAPPLIEDPARTSperISO80601-2-61Clause201.6.
300CARESCAPEONE2094480-001
