OPERATION
101
DCW FAIL Timing
DISCHARGE
Output V
time
START
TEST
FAIL
RAMP
UP
TEST TIME
IR FAIL Timing
DISCHARGE
Output V
time
START
TEST
FAIL
RAMP
UP
TEST TIME
GB FAIL Timing
START
FAIL
Output I
TEST
Contact
RAMP Test
time
Time 0.1s 0.1s
UP Time
CONT FAIL
Timing
Output I
time
START
TEST
FAIL
Test Time
