GW Instek GPT-10000 Series User Manual

OPERATION
137
Interface Settings
Description
The interface settings allows user to choose the
remote interface configuration. USB, RS232, LAN
(optional) and GPIB (optional) can be selected.
Steps
1. Press the SYSTEM button on the
front panel when the tester is
under READY status in either
MANU or AUTO test.
2. The SYSTEM page will be shown.
Press the UP/DOWN arrow soft-
keys to move the cursor to the
INTERFACE setting.
3. Press the ENTER soft-key to enter
the Interface setting followed by
using the scroll wheel to select the
Interface options.
Interface Options
RS-232, USB, GPIB, LAN
