GW Instek GPT-10000 Series - Page 279

APPENDIX
279
Interface
REMOTE (Remote terminal)
Yes
SIGNAL IO
Yes
RS232
Yes
USB (Device)
Yes (USB 2.0)
Rear Output
Yes
USB (Host) for data output port
Yes (USB 2.0)
GPIB
Yes (Optional)
LAN
Yes (Optional)
Barcode Reader USB port
Yes (USB-VCP)
Table 1: Output Limitation in Withstanding Voltage Testing
Function
Upper Current
Pause
Output Time
AC
GPT-
15XXX
80mA≤I
≤100mA
0.001mA
I 80mA
At least as
long as the
output time
Maximum 240
seconds
Not necessary
Continuous
output possible
GPT-
12XXX
30mA≤I≤
40mA
0.001mA
≤I<30mA
At least as
long as the
output time
Maximum 240
seconds
Not necessary
Continuous
output possible
DC
GPT-
15XXX
0.001mA
I 20mA
Not necessary
Continuous
output possible
GPT-
15012
0.001mA
≤I≤10mA
GPT-
12XXX
0.001mA
≤I≤10mA
GB
15A<I≤32A
At least as
long as the
output time
999.9 seconds
3A≤I≤15A
Not necessary
999.9 seconds
NOTE: Output Time = Ramp Time + Test Time.
