Table 2: GPT-10000 capacitive load table
Test Condition
Maximum
Test Voltage
DCW
HI-SET
Current
RAMP Time
↗
Capacitive Load
1
1.000kV
I≧10.00mA
T≧1.0S
4.7µF
2
2.000kV
I≧7.00mA
T≧1.0S
1.65µF
3
3.000kV
I≧8.00mA
T≧1.0S
1.32µF
4
4.000kV
I≧11.00mA
T≧1.0S
1.32µF
5
5.000kV
I≧7.00mA
T≧1.0S
0.66µF
6
6.000kV
I≧8.00mA
T≧1.0S
0.66µF
7
7.000kV
I≧9.00mA
T≧1.0S
0.66uF
8
8.000kV
I≧6.00mA
T≧1.0S
0.33uF
9
9.000kV
I≧7.00mA
T≧1.0S
0.33uF
10
10.00kV
I≧8.00mA
T≧1.0S
0.33uF
11
11.00kV
I≧9.00mA
T≧1.0S
0.33uF
12
12.00kV
I≧10.00mA
T≧1.0S
0.33uF
