HEIDENHAIN CNC PILOT 640 - Page 677

Overview of G codes | Overview of G commands in the CONTOUR section
10
HEIDENHAIN | User's Manual smart.Turn and DIN Programming | 12/2017
677
G commands for Y-axis contours
XY plane Page
G170-Geo Start point
Page 569
G171-Geo Linear face
Page 569
G172-Geo Circ. arc face ccw
Page 570
G173-Geo Circ. arc face ccw
Page 570
G370-Geo Hole in XY plane
Page 571
G371-Geo Linear slot in XY plane
Page 572
G372-Geo Slot cw in XY plane
Page 572
G373-Geo Slot ccw in XY plane
Page 572
G374-Geo Full circle in XY plane
Page 573
G375-Geo Rectangle in XY plane
Page 573
G377-Geo Polygon in XY plane
Page 574
G471-Geo Linear pattern, face
Page 575
G472-Geo Circular patt., face
Page 576
G376-Geo Single surface in XY plane
Page 577
G477-Geo Centr. polygon, face
Page 577
YZ plane Page
G180-Geo Start point
Page 578
G181-Geo Surface linear
Page 578
G182-Geo Circ.arc surface ccw
Page 579
G183-Geo Circ.arc surface ccw
Page 579
G380-Geo Hole in YZ plane
Page 580
G381-Geo Linear slot in YZ plane
Page 580
G382-Geo Slot cw in YZ plane
Page 581
G383-Geo Slot ccw in YZ plane
Page 581
G384-Geo Full circle in YZ plane
Page 581
G385-Geo Rectangle in YZ plane
Page 582
G387-Geo Polygon in YZ plane
Page 582
G481-Geo Lin. patt., side v.
Page 583
G482-Geo Circ. patt, side v.
Page 584
G386-Geo Single surface in XY plane
Page 585
G487-Geo Centr. polyg., surf.
Page 585
