Global Functions
DML-1200 w/Axon Embedded Graphic Engine 24/12/2010 _____________________________________________________________________________ 38
13
DotP and Resample
Red Green Blue
14
Color Cycle cycles colors with DMX value controlling cycle speed.
Red Green Blue
15
All or Nothing sets color values > mod value = 255 and all other color
values = 0
Red Green Blue
16
Solid color RGB
Red Green Blue
17
RGB Invert
From Red
to Cyan
From Green to
Magenta
From Blue
to Yellow
18
RGB, Invert and Swap to GBR
Red to Green Green to Blue Blue to Red
19
RGB, Invert and Swap to BRG
Red to Blue Green to Red Blue to Green
20
Edge Detect Color
Horizontal search
size
Vertical
search size
Comparison
threshold
21
Edge Detect B/W
Horizontal
search size
Vertical
search size
Comparison
threshold
22
Texture Ripple, Horizontal
Amplitude Frequency Phase
23
Texture Ripple, Vertical
Amplitude Frequency Phase
24
Texture Ripple, Circular
Amplitude Frequency Phase and Direction
25
Texture Ripple, Circular Asymmetrical
Amplitude Frequency Phase
26
Transparent Color Fine selects key color using Modifier channels
Red Green Blue
27
Transparent Color Medium selects key color using Modifier channels
Red Green Blue
28
Transparent Color Coarse selects key color using Modifier channels
Red Green Blue
29
Transparent Color Invert, Fine selects key color using Modifier
channels
Red Green Blue
30
Transparent Color Invert, Medium selects key color using Modifier
channels
Red Green Blue
31
Transparent Color Invert, Coarse selects key color using Modifier
channels
Red Green Blue
32
Scan Line converts image colors to colors in a single line of the
Selects
scan line
Fades to
converted image
Not used
33
Transparent Wipes “opens” the selected graphic to reveal another
graphic positioned behind it
Area of wipe
Selects center
of wipe
Selects from
6 wipe options
34
Pixel Twist swirls a portion of the texture
Twist center
on X axis
Twist center
on Y axis
Direction and
amount of twist
35
Picture-in-picture duplicates the texture and overlays it on the original
Subpicture center
on Xaxis
Subpicture center
on Yaxis
Subpicture size
36
Magnifying Lens creates a virtual convex lens that magnifies a
portion of the texture
Lens center
on X axis
Lens center
on Y axis
Lens size
37
Magnifying Lens 2 creates a virtual double convex lens that
magnifies a portion of the texture.
Lens center
on X axis
Lens center
on Y axis
Lens size
38
Cartoon Edge creates variable outline around picture elements
Reduces Color Enhances Contrast
Edge detection
sensitivity
39
Color DeConverge separates and offsets image color components
from original position
Moves Red
up
Moves Green
down and right
Moves Blue
down and left
40
Horizontal Mirror creates a mirror effect
Defines
mirror center
Not Used Not Used
41
RGB Swap to BGR redefines component color
Red to Blue Green Blue to Red
42
RGB Swap to RBG redefines component color
Red Green to Blue Blue to Green
43
RGB Swap to GRB redefines component color
Red to Green Green to Red Blue
44
Colorize Gray Scale maps pixel intensity to color
Selects Color
Scheme
Selects zero intensity
point
Controls
fading
45
Intensity Key turns pixels of selected intensity transparent
Selects Color
Scheme
Sets Intensity
bandwidth
Controls
Transparency
46
Raindrop simulates raindrops falling on a liquid surface
Controls size/speed
Seeds random
# generator
Controls
raindrop rate
DMX
Value
Effect Mode Name/Description
Adjustments
Modifier 1 Modifier 2 Modifier 3
