CRANKSHAFTITRANSMISSION/KICKSTARTER
INSPECTION
Inspect the following:
-
Cam
chain guide sprocket
[1]
for wear or damage
[1J
-
Cam
chain guide sprocket spindle
[2J
for
wear
or
damage
- Spindle journal
[11
for abnormal
wear
or
damage
INSTALLATION
Apply engine oil
to
the cam chain guide sprocket
,---"
spindle
11]
sliding surface.
Install the spindle to the left crankcase, hold the
sprocket
12J
and lighten the
sp
indle to the specified
torque.
TORQUE: 10 N-m (1.0
kgf
-m,
7lbHt
)
Assemble the crankcase (page 12-17).
CRANKCASE ASSEMBLY
Clean off the sealant from the left and right crankcase
mating surfaces.
Inslallths
dowel pins
111
onlo
the right crankcase.
12·17
To Next Page
