FRONT WHEEUBRAKE/SUSPENSION/STEERING
FORK
14·18
REMOVAL
Remove
the
following:
- Number plate (page 2-5)
- Front wheel (page
14
-9)
loos
en
the fork lop bridge pinch bolt (1).
loosen
the fork bottom bridge pinch boll [1).
Remove the fork leg [2].
When the fork
Is
to be disassembled, lower the
forX;
leg
~--==
and lighten the bottom pinch bolt (1].
loosen
the fork cap bolt
[2J.
but
do
not remove it yet.
Loosen the fork bottom pinch bolt and remove the fork
leg.
DISASSEMBLY
Hold
the
Iorio;
slider
in
a
vice
with
soft
Jaws
or a shop
r-----------
--,-,----,
towel. (1)
Loosen the fork socket bolt
(1)
. but
do
nol
remove it yet.
