Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 50 Installation & Operation Manual
Honeywell
To complete the installation, bind each function to its I/O within the
Configuration menu.
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
CN-101
1 DO-EMR-1 A EMR1_no Contact for
External
Supply
Low frequency
slow switching
AC or DC output
control.
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Deadman callout
Deadman bell
Secondary
interface for:
Actuator output
Additive solenoid
2 DO-EMR-1 B EMR_common Contact for
External load
switching
3 DO-EMR-2 A EMR2_no Contact for
External
Supply
4 DO-EMR-2 B EMR_common Contact for
External load
switching
5 DO-EMR-3 A EMR3_no Contact for
External
Supply
6 DO-EMR-3 B EMR_common Contact for
External load
switching
7 DO-EMR-4 A EMR4_no Contact for
External
Supply
8 DO-EMR-4 B EMR_common Contact for
External load
switching
