Operation - Stream Configuration
Fusion4 MSC-L Part No.: 4418309_Rev09
5 - 176 Installation & Operation Manual
Honeywell
NOTE: I/O bindings must be configured for each stream.
Also, following entities must be unique for each
stream.
 Additive stream meter
 Pump feedback
 Additive temperature
 Solenoid control
 Block valve
 Injection feedback
 Pump start
 Factored pulse out
To configure Input/Output entities
 On the Main Menu screen, select the Stream Configuration icon.
The Stream Configuration screen appears.
 On the Stream Configuration screen, select Additive streams.
The Stream Config. . Additive Stream Selection screen appears.
 On the Stream Config. . Additive Stream Selection screen, select
any one of the stream or all the streams.
The Additive Stream Config . Stream n screen appears.
 On the Additive Stream Config . Stream n screen, select <I/O
binding>.
 Select <Inputs> or <Outputs> and then select <OK> on the Fusion4 IR
controller, Fusion4 LAD, or the integrated keyboard.
The following table provides the possible entities and the I/O
functions to which a specific entity can be linked.
5.14.2.2.1 The I/O Bindings . Input Parameters
NOTE: The default value for all the Input entities are None.
Entity Description Can be linked to...
[Additive stream meter]
With this entity you can select the
physical pulse input for an additive
pulse input.
Any of the unused QPI-1A to QPI-6B (for
additive streams 1 to 12).
Any of the unused QPI-7A to QPI-12B (for
product streams 13 to 24).
[Pump feedback]
With this entity you can select physical
source for the pump feedback function.
Any of the unused DI-DC-n, DI-AC-n, QPI -
n, AI-n, or None.
[Tank low level switch]
With this entity you can select the
physical source for the tank low level
function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Tank empty switch]
With this entity you can select the
physical source for the tank empty
function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
