Operation - Stream Configuration
Fusion4 MSC-L Part No.: 4418309_Rev09
5 - 146 Installation & Operation Manual
Honeywell
5.14.1.2.1 The I/O Bindings . Input Parameters
NOTE: The default value for the Input entities are None.
NOTE: When the temperature and/or pressure correction is
used, link them as below for the W&M compliance.
Select the I/O binding for the Product Temperature as RTD input (4-wire).
Select the I/O binding for the Product Pressure as AI (4-20 mA).
Select the I/O binding for the Product Density as AI (4-20 mA) or use the lab
density
.
Entity Description Can be linked to...
[Product stream meter]
With this entity you can select the physical
source for the product stream meter function.
Any of the unused QPI-1A to QPI-6B (for
product streams 1 to 6).
Any of the unused QPI-7A to QPI-12B (for
product streams 7 to 12).
[Product temperature]
With this entity you can select the physical
source for the product stream temperature
function.
RTD-1, RTD-2, RTD-3, RTD-4, RTD-5, RTD-
6, AI-1, AI-2, AI-3, AI-4, AI-5, AI-6, AI-7, AI-8,
AI-9, AI-10, AI-11, AI-12, AI-13, AI-14, None
[Product pressure]
With this entity you can select the physical
source for the product stream pressure
function.
AI-1, AI-2, AI-3, AI-4, AI-5, AI-6, AI-7, I-8, AI-
9, AI-10, AI-11, AI-12, AI-13, AI-14, None
[Product density]
With this entity you can select the physical
source for the product stream density
function.
AI-1, AI-2, AI-3, AI-4, AI-5, AI-6, AI-7, I-8, AI-
9, AI-10, AI-11, AI-12, AI-13, AI-14, None
[Pump feedback]
With this entity you can select the physical
source for the pump feedback function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Tank low level switch]
With this entity you can select the
physical source for the tank low level
function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Tank empty switch]
With this entity you can select the
physical source for the tank empty
function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Hydraulic pump
feedback]
With this entity you can select the physical
source for the hydraulic pump feedback
function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Block valve feedback]
With this entity you can select the physical
source for the block valve feedback function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Block valve open
feedback]
With this entity you can select the physical
source for the block valve open feedback
function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Block valve closed
feedback]
With this entity you can select the physical
source for the block valve closed feedback
function.
Any of the unused DI-DC-n, DI-AC-n, QPI-n,
AI-n, or None.
[Product vapor
pressure]
With this entity you can select the physical
source for the product stream vapour
pressure function.
AI-1, AI-2, AI-3, AI-4, AI-5, AI-6, AI-7, I-8, AI-
9, AI-10, AI-11, AI-12, AI-13, AI-14, None
