Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 4 - 69
4.7.9 ARM-2-BACKPLANE-MSC Terminal Assignment Guide
The following table provides information for the basic function
assignment to specific terminals.
Majority of the MSC-L functions can be assigned to multiple I/O.
To complete the installation, bind each function to its I/O within the
Configuration Menu.
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
CN-201
1 DO-EMR-21 A EMR21_no Signal - Output Low frequency
slow switching
AC or DC output
control.
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Deadman callout
Deadman bell
Secondary
interface for:
Actuator output
Additive solenoid
2 DO-EMR-21 B EMR_common Neutral
3 DO-EMR-22 A EMR22_no Signal - Output
4 DO-EMR-22 B EMR_common Neutral
5 DO-EMR-23 A EMR23_no Signal - Output
6 DO-EMR-23 B EMR_common Neutral
7 DO-EMR-24 A EMR24_no Signal - Output
8 DO-EMR-24 B EMR_common Neutral
CN-202
1 DO-EMR-25 A EMR25_no Signal - Output Low frequency
slow switching
AC or DC output
control.
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Deadman callout
Deadman bell
Secondary
interface for:
Actuator output
Additive solenoid
2 DO-EMR-25 B EMR_common Neutral
3 DO-EMR-26 A EMR26_no Signal - Output
4 DO-EMR-26 B EMR_common Neutral
5 DO-EMR-27 A EMR27_no Signal - Output
6 DO-EMR-27 B EMR_common Neutral
7 DO-EMR-28 A EMR28_no Signal - Output
8 DO-EMR-28 B EMR_common Neutral
