Honeywell Fusion4 MSC-L User Manual

Operation - Stream Configuration
Fusion4 MSC-L Part No.: 4418309_Rev09
5 - 152 Installation & Operation Manual
Honeywell
NOTE: For accurate DCV control performance, it is recom-
mended to configure the Digital Outputs (DO's)
locally. That is, use the SSR's for valve control on the
CAN-ARM-MSC board where the flow meter is
configured to the Pulse Input(s) (PI).
5.14.1.4 Volume Conversion
5.14.1.4.1 Volume Conversion Essential Information
The MSC-L volume conversions are meant for the conversion of the
measured Gross Observed Volume (GOV) to the Gross Standard
Volume (GSV).
The GSV is defined at base (reference) conditions for temperature and
pressure, and hence it is suitable for highly accurate custody transfer of
various products.
NOTE: Configured/observed pressures are gauge
pressures, i.e. pressures above standard atmos-
pheric pressure of 101.325 kPa, so it is important
that gauge (not absolute) pressure transmitters are
used as pressure sensors. Also, in case of NGL and
LPG (TP27-07 commodity group), configured base
[Low flow 2SV in initial phase]
With this entity you can configure the
digital value of the
[Low flow 2SV in
initial phase]
output for the selected
product stream in initial flow phase.
<Active> (default)
<Inactive>
[Low flow 2SV in pre-stop
phase]
With this entity you can configure the
digital value of the [
Low flow 2SV in
pre-stop phase]
output for the selected
product stream in initial flow phase.
<Active> (default)
<Inactive>
[Low flow 2SV in full flow
phase]
With this entity you can configure the
digital value of the
[Low flow 2SV in full
flow phase]
output for the selected
product stream in initial flow phase.
<Active> (default)
<Inactive>
[High flow 2SV in initial phase]
With this entity you can configure the
digital value of the
[High flow 2SV in
initial phase]
output for the selected
product stream in initial flow phase.
<Active>
<Inactive>
(default)
[High flow 2SV in pre-stop
phase]
With this entity you can configure the
digital value of the
[High flow 2SV in
pre-stop phase] output for the selected
product stream in initial flow phase.
<Active>
<Inactive>
(default)
[High flow 2SV in full flow
phase]
With this entity you can configure the
digital value of the
[High flow 2SV in full
flow phase] output for the selected
product stream in initial flow phase.
<Active> (default)
<Inactive>
Entity Description Value range
